A compact and sophisticated inboard boat to elevate your boating experience. With its sleek design and meticulous craftsmanship, the H1 offers a perfect balance of performance and style. Measuring at an overall length of 20’1″, this versatile boat is ideal for navigating both inland waters and coastal areas with ease.
Four Winns H1
| Length overall | 20'1" / 6.12 m |
| LOA w/ extended swim platform | 21'90" / 6.63 m |
| Hull length | 19'1" / 6.06 m |
| Beam | 8'50" / 2.54 m |
| CE Certification | D9 |
| Fuel capacity | 32 gal / 121 l |
| Approx. Draft Up | 18" / 0.46 m |
| Approx. Draft Down | 35" / 0.89 m |
| Persons capacity | 8 CE |
| Maximum Capacity | 1475 lbs / 669 kg |
| Lightship Displacement (w/o engine) | 2600 lbs / 1180 kg |
| Lightship Displacement (w/ engine) | 3500 lbs / 1590 kg |
| Max. engine power | 280 hp/cv |
| Deadrise | 18 ° |
| Bridge Clearance | 3'90" / 1.14 m |
| Bridge Clearance w/ Arch or Tower | 6'11" / 2.11 m |
| Total height | 5'30" / 1.6 m |
| Total height on trailer | 7'1" / 2.16 m |
| Height on Trailer w/Wakeboard Tower Dn | 8'70" / 2.62 m |
| Height on Trailer w/Wakeboard Tower Up | 10'30" / 3.12 m |
| Trailer weight single axe | 720 lbs / 327 kg |
| Trailer Weight Tandem Axle | 900 lbs / 408 kg |
| Storage length on trailer | 20'11" / 6.38 m |
| Storage length on trailer with extended swim platform | 22'70" / 6.88 m |
| Stripe color | White |
| Integral hull | White |
| Cockpit color choices | Lunar |
| Hull and deck | Bow & stern eyes, stainless steel; Cleats, fixed, stainless steel; Exterior color, all white; Exterior gel accent stripe, choice of color; Fiberglass stringer system; Horn; Ladder, stern, angled, deep-reach, hidden w/ wide steps; Meets applicable USCG & Canadian regs; NMMA certified using ABYC stds.; Navigation lights, LED; Rub rail w/ stainless steel insert; Stable-Vee® hull next generation; Swim platform, stern; Thru-hull fittings, stainless steel; Winning edge owner protection plan; Windshield header, polished; Windshield w/walk-thru, full-height, curved glass, exclusive design; |
| Tow sports accessories | Ski tow, stern, stainless steel; Pre-Drill Tower Holes; |
| Cockpit | Assist handle(s), stainless steel, vinyl wrapped; Beverage holder(s), stainless steel; Coaming pads w/ rich hand-fitted vinyl & comfort padding; Choice of standard upholstery color; Cooler, carry-on; Courtesy lights, Blue LED; Fiberglass liner, skid-resistant, self-draining; Interior color scheme, choice of color; Port console, glove box; Seating, bow cushions, hinged; Seating, cockpit, U-shaped; Seating, ComfortRide, flip-up bucket bolster(s); Ski locker, in-floor, w/ gas-assist hinged lid & mat; Storage locker, in-floor, w/ gas-assist hinged lid & mat; Storage, bow & cockpit, beneath seats; Storage, cockpit, sidewall storage w/ beverage holders; Sundeck, aft w/ chaise lounge; Trash receptacle(s); Upholstery, premium contoured vinyl w/ custom detailing; Walk-thru transom; Water intrusion management system; |
| Helm | Dash, rich hand-wrapped vinyl, w/ custom detailing & LED accent lighting; Emergency engine shut-off; Instrumentation, helm: touch screen, integrated gauges and GPS speed; Lighted switches, LED; Steering wheel, deluxe, tilt; |
| Entertainment | Speakers, (4); Stereo Remote, Helm & Transom; USB port(s); |
| Engine / Systems / Drive | Battery(ies); Bilge blower(s); Bilge pump(s), automatic; Engine blower; Engine vents; Outlet, 12V; Outlet, USB charge port(s); Seanapps System; Wiring harness w/ sealed connectors and tin coating for corrosion resistance; Battery Certificate; Battery Tray; |
| Trailer | Four Winns® custom-matched trailer w/ brakes, single axle; Jack-stand, heavy-duty; Self-centering bunks; Submersible lighting, LED; Swing-away tongue; Wheels, aluminum; |
